Monday, November 13, 2017

QNAP NAS 安裝OpenHAB 來實現智慧家庭

QNAP NAS 安裝OpenHAB

OpenHAB http://www.openhab.org/



Step1:
插入Z-Wave的USB之後
用ssh連到NAS
輸入以下指令(4.3.3 0154 TS-251A 確認可以)

"insmod /usr/local/modules/cdc-acm.ko
"chmod 777 /dev/ttyACM*"

Step2:

兩種方法:用Container Station UI建立或是連SSH進NAS輸入指令建立
(方法1)


內置圖片 1

內置圖片 3
內置圖片 2

(方法2)

SSH輸入
docker run \
        --name openhab-zwave2 \
-p 18080:8080 \
-p 8443:8443 \
-p 5555:5555 \
--privileged \
openhab/openhab:2.1.0-snapshot-amd64

Step3:
設定OpenHab
內置圖片 4

內置圖片 30
內置圖片 25
內置圖片 26
內置圖片 27
內置圖片 28
如果/dev/ttyACM0無法連線的話,SSH連進NAS輸入 ls -al /dev/ttyACM*看看是哪個port

內置圖片 29
內置圖片 31

內置圖片 32
內置圖片 34
內置圖片 33

點選藍色圈圈可以加入功能到Control 面板中
內置圖片 35


!!!!!!!!!注意!!!!!!!!

每次重新開機都要打Step1那兩行
並且 /dev/ttyACM0可能會跑掉
輸入 ls -al /dev/ttyACM*看看在哪一個port 在設定中更換

Tuesday, November 7, 2017

Chinese Culture University Safeguards Campus Environment with QNAP VioStor NVR & CMS

Chinese Culture University Safeguards Campus Environment with QNAP VioStor NVR & CMS
Company/Institute: Chinese Culture University
Location: Taipei, Taiwan
Official Website: http://www.pccu.edu.tw/intl/index-e.htm

Background
Founded in 1962, the Chinese Culture University (CCU) is one of the largest universities in Taiwan with an enrollment of about 32,000 students. It has an educational vision to grow and promote Chinese culture, particularly tradition Chinese arts and physical education. CCU is now organized into twelve academic colleges including Liberal Arts, Foreign Language and Literature, Journalism and Communications, Arts, Environmental Design, and more.

SG Group (Société Générale) Benefits from QNAP Security’s NVR Solution with Storage Expansion Flexibility

SG Group (Société Générale) Benefits from QNAP Security’s NVR Solution with Storage Expansion Flexibility
Background
Bank Republic, one of the Georgia's oldest privately owned banks, was founded in 1991 and is a leading commercial bank in Georgia. The Bank serves its clients through 37 branches and service centers. Société Générale is a French multinational banking and financial services company. In 2006, the Société Générale Group took over the controlling interests of the Bank Republic in Georgia, with the Bank Republic becoming a member of the international group Société Générale.


Recovery Ranch Relies on QNAP Security Surveillance Solution to Safeguard its Residents Community

Recovery Ranch Relies on QNAP Security Surveillance Solution to Safeguard its Residents Community
Background
Recovery Ranch, located in Nashville, Tennessee in the USA, is a special rehabilitation center for clients with addictive disorders, eating or mood disorders, or in need of psychosomatic recovery for an improved quality of life.

Recovery Ranch employs 160 therapists and administrative personnel, serving over 75 clients at a time, with 24/7 care for different treatments, hence it is a large facility with residents of diverse backgrounds.


The Harmony Public School Continues to Choose QNAP VioStor NVR for its Expanding Surveillance Deployment

The Harmony Public School Continues to Choose QNAP VioStor NVR for its Expanding Surveillance Deployment
Background
Harmony Public School, a Texas-based non-profit organization, was established by a group of dedicated educators and university academicians. The school is high performing K-12 college preparatory charter school that focuses on math, science, engineering and computer technologies.


US Large Outdoor Supply Retailer Tightens Up Security with QNAP Security Surveillance Solution

US Large Outdoor Supply Retailer Tightens Up Security with QNAP Security Surveillance Solution
Background
Great Lakes Outdoor Supply, Inc. is located in Northern Ohio, USA, and is an outdoor sporting goods retailer. The primary sporting goods it sells are archery, hunting, shooting sports, and fishing. Besides selling general sporting goods for outdoor activities, the company is also a firearms retailer, supplying guns, accessories and ammunition.
